Fully automatic robotic welding workstation

Technical Specifications

Parameter	Specification	Parameter	Specification
Robot Body	YHR-1450	Control Cabinet	Highly Integrated Drive and Control
Teach Pendant	RW8800	Collision-Proof Welding Torch	ROYEE
Welding Power Supply	AOTAI / MEGMEET	Wire Feeder	AOTAI / MEGMEET
External Axis	DZ-1800	Tooling Fixture	WWH-1500
Communication Controller	CAN/OPEN	Scheduled Start/Stop	Start, Stop, Pause

Machine Features

1. Working radius of 1450mm with a hollow design to avoid interference with the workpiece.

2. Compact size, high control accuracy, and intelligent self-diagnosis.

3. Small, lightweight, simple, and intuitive.

4. Built-in collision protection to safeguard the welding torch.

5. Reliable soft-switch inverter technology with ultra-low spatter and full digital control, achieving precise control of droplet transfer. This results in minimal welding deformation and ensures consistent welding quality with intelligent parameter matching.

6. Built-in encoder feedback that maintains stable wire feeding even if external factors such as voltage or wire feeding resistance change.

7. Flip positioner enabling full-position welding on both front and back sides of the workpiece.

8. Automatic positioning and clamping based on the shape and size of the workpiece. Independently developed design that is convenient and efficient, supporting batch continuous welding.

9. Real-time communication with precise current and voltage control.

10. Optional dual-station configuration available.
